model
|
|---|
| CT-SV-1/4 |
| CT-SV-3/8 |
| CT-SV-1/2 |
| CT-SV-5/8 |
| CT-SV-3/4 |
| CT-SV-7/8 |
|
Pipe Dia.
|
Max flow
|
Connection Thread |
Cap Thread
|
Charging Port Thread
|
|---|---|---|---|---|
| 1/4" | 0.43 | 7/16-20UNF | M16X1 | 7/16-20UNF 1/2-20UNF |
| 3/8" | 1.33 | 5/8-18UNF | M16X1 | 7/16-20UNF 1/2-20UNF |
| 1/2" | 1.95 | 3/4-16UNF | M18X1 | 7/16-20UNF 1/2-20UNF |
| 5/8" | 3.62 | 7/8-14UNF | M22X1 | 7/16-20UNF 1/2-20UNF |
| 3/4" | 5.35 | 17/16-14UNF | M25X1 | 7/16-20UNF 1/2-20UNF |
| 7/8" | 7.13 | 19/16-12UNF | M30X1.5 | 7/16-20UNF 1/2-20UNF |
