model
number
|
|---|
CT-EXV-3.2 |
CT-EXV-3.0 |
| CT-EXV-2.4 |
| CT-EXV-2.2 |
| CT-EXV-2.0 |
| CT-EXV-1.8 |
| CT-EXV-1.6 |
| CT-EXV-1.5 |
| CT-EXV-1. |
|
TUBE DIA.
mm
|
R22 CAPACITY
KW (USRT)
|
FULLY OPEN
PULSE
|
OPEN VALVE
PULSE
|
PULSE
FREQUENCY (PPS)R22
|
R22
MAX. OPERATION PRESSURE DIFFERENCE (MPA）
|
R407C
MAX. OPERATION PRESSURE DIFFERENCE (MPA）
|
R410A
MAX. OPERATION PRESSURE DIFFERENCE (MPA）
|
CONNECTION
PIPE (MM)
|
R22
MAX. WORKING PRESSURE
|
R407C
MAX. WORKING PRESSU
|
R410A
MAX. WORKING PRESSURE
|
|---|---|---|---|---|---|---|---|---|---|---|---|
ø 3.2 |
28.2 (8.0) | 500 | 32± 20 | 30~90 | 2.26 | 2.48 | 0~79P：≥2.26 79~500P：≥3.43 | ø 6.35x0.7 | 3 | 3.3 | 4.2 |
ø 3.0 |
21.1 (6.0) | 500 | 32± 20 | 30~90 | 2.26 | 2.48 | 0~79P：≥2.26 79~500P：≥3.43 | ø 6.35x0.7 | 3 | 3.3 | 4.2 |
| ø 2.4 | 17.6 (5.0) | 500 | 32± 20 | 30~90 | 2.26 | 2.48 | 3.43 | ø 6.35x0.7 | 3 | 3.3 | 4.2 |
| ø 2.2 | 10.6 (3.0) | 500 | 32± 20 | 30~90 | 2.26 | 2.48 | 3.43 | ø 6.35x0.7 | 3 | 3.3 | 4.2 |
| ø 2.0 | 8.8 (2.5) | 500 | 32± 20 | 30~90 | 2.26 | 2.48 | 3.43 | ø 6.35x0.7 | 3 | 3.3 | 4.2 |
| ø 1.8 | 7 (2.0) | 500 | 32± 20 | 30~90 | 2.26 | 2.48 | 3.43 | ø 6.35x0.7 | 3 | 3.3 | 4.2 |
| ø 1.6 | 5.25 (1.5) | 500 | 32± 20 | 30~90 | 2.26 | 2.48 | 3.43 | ø 6.35x0.7 | 3 | 3.3 | 4.2 |
| ø 1.5 | 4.38 (1.25) | 500 | 32± 20 | 30~90 | 2.26 | 2.48 | 3.43 | ø 6.35x0.7 | 3 | 3.3 | 4.2 |
| ø 1.3 | 3.5 (1.0) | 500 | 32± 20 | 30~90 | 2.26 | 2.48 | 3.43 | ø 6.35x0.7 | 3 | 3.3 | 4.2 |
