model
|
|---|
| CT-SV-1/4ODF |
| CT-SV-1/4SAE |
| CT-SV-3/8ODF |
| CT-SV-3/8SAE |
| CT-SV-1/2ODF |
| CT-SV-1/2SAE |
| CT-SV-5/8ODF |
| CT-SV-5/8SAE |
| CT-SV-3/4ODF |
| CT-SV-3/4SAE |
|
KV (m3/h)
|
L
|
L1 |
W
|
H1
|
H2
|
D
|
CONNECTION
|
weight(g)
Sgn |
|---|---|---|---|---|---|---|---|---|
| 0.08 | 109 | 7 | 26.5 | 14 | 71 | 6.35 | 1/4ODF | 381 |
| 0.08 | 59 | 12 | 26.5 | 14 | 71 | 1/4SAE | 381 | |
| 0.8 | 154 | 9 | 45 | 18.3 | 90 | 9.52 | 3/8ODF | 614 |
| 0.8 | 89 | 15.5 | 45 | 18.3 | 90 | 3/8SAE | 611 | |
| 1.4 | 179 | 10 | 45 | 18.3 | 90 | 12.7 | 1/2ODF | 627 |
| 1.4 | 92 | 17 | 45 | 18.3 | 90 | 1/2SAE | 613 | |
| 2.1 | 202 | 12 | 58 | 22 | 95 | 15.9 | 5/8ODF | 962 |
| 2.1 | 114 | 20.5 | 58 | 22 | 95 | 5/8SAE | 938 | |
| 2.6 | 222 | 13 | 58 | 22 | 95 | 19.1 | 3/4ODF | 913 |
| 2.6 | 115 | 21 | 58 | 22 | 95 | 3/4SAE | 977 |
