Model
spec
|
|---|
| Single Stage |
| VE115N |
| VE125N |
| VE135N |
| VE160N |
| VE180N |
| Dual Stage |
| VE215N |
| VE225N |
| VE245N |
| VE260N |
| VE280N |
| VE2100N |
|
fLOW RATE
50hz (cfm)
|
FLOW RATE
50hz (l/min)
|
Flow rate
60hz (cfm)
|
flow rate
60hz (l/min)
|
UL. VACUUM
(PARTIAL PRESSURE) (pa)
|
UL. VACUUM
(TOTAL PRESSURE) (Micron)
|
Power
(H/P)
|
Inlet Port
(inches)
|
oil capacity
(ml)
|
Dimension
(mm)
|
Weight
(kg)
|
MOQ
(pcs)
|
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1.8 | 51 | 2.0 | 57 | 2 | 150 | 1/4 | 1/4''SAE | 250 | 290*124*224 | 6.6 | 10 |
| 2.5 | 70 | 3.0 | 80 | 2 | 150 | 1/4 | 1/4''SAE | 250 | 290*124*224 | 7.1 | 10 |
| 3.5 | 100 | 4.0 | 113 | 2 | 150 | 1/3 | 1/4''&3/8''SAE | 250 | 318*124*234 | 8 | 10 |
| 6 | 170 | 7 | 198 | 2 | 150 | 1/2 | 1/4''&3/8''SAE | 415 | 338*138*244 | 9.9 | 10 |
| 8 | 226 | 9 | 254 | 2 | 150 | 3/4 | 1/4''&3/8''SAE | 660 | 395*145*257 | 14.6 | 10 |
| 1.5 | 42 | 1.8 | 50 | 2*10-1 | 15 | 1/4 | 1/4''SAE | 200 | 308*124*224 | 7.5 | 10 |
| 2.5 | 70 | 3.0 | 84 | 2*10-1 | 15 | 1/3 | 1/4''SAE | 200 | 318*124*234 | 8,5 | 10 |
| 4.5 | 128 | 5.0 | 142 | 2*10-1 | 15 | 1/2 | 1/4''&3/8''SAE | 325 | 338*138*244 | 10.4 | 10 |
| 6.0 | 170 | 7.0 | 198 | 2*10-1 | 15 | 3/4 | 1/4''&3/8''SAE | 580 | 395*145*257 | 15.8 | 10 |
| 8.0 | 226 | 9.0 | 254 | 2*10-1 | 15 | 1 | 1/4''&3/8''SAE | 500 | 395*145*257 | 16.2 | 10 |
| 10 | 283 | 12 | 340 | 2*10-1 | 15 | 1 | 1/4''&3/8''SAE | 590 | 395*145*257 | 16.7 | 10 |
