Model
spec
|
|---|
| Single Stage |
| V-i120SV |
| V-i140SV |
| V-i160SV |
| V-i180SV |
| Dual Stage |
| V-i220SV |
| V-i240SV |
| V-i260SV |
| V-i280SV |
|
fLOW RATE
50hz (cfm)
|
FLOW RATE
50hz (l/min)
|
Flow rate
60hz (cfm)
|
flow rate
60hz (l/min)
|
UL. VACUUM
(PARTIAL PRESSURE) (pa)
|
UL. VACUUM
(TOTAL PRESSURE) (Micron)
|
Power
(H/P)
|
Inlet Port
(inches)
|
oil capacity
(ml)
|
Dimension
(mm)
|
Weight
(kg)
|
MOQ
(pcs)
|
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1.8 | 51 | 2.0 | 57 | 2 | 150 | 1/4 | 1/4''SAE | 250 | 290*124*255 | 6.7 | 10 |
| 3.5 | 100 | 4.0 | 113 | 2 | 150 | 1/3 | 1/4''SAE | 250 | 318*124*265 | 8.6 | 10 |
| 5.0 | 142 | 6.0 | 170 | 2 | 150 | 1/2 | 1/4''SAE | 415 | 338*138*275 | 10.3 | 10 |
| 7.0 | 198 | 8 | 226 | 2 | 150 | 3/4 | 1/4''SAE | 660 | 395*145*318 | 15.4 | 10 |
| 1.8 | 51 | 2.0 | 57 | 2*10-1 | 15 | 1/3 | 1/4''SAE | 200 | 318*124*265 | 9 | 10 |
| 3.5 | 100 | 4 | 113 | 2*10-1 | 15 | 1/2 | 1/4''SAE | 325 | 338*138*275 | 11 | 10 |
| 5.0 | 142 | 6.0 | 170 | 2*10-1 | 15 | 3/4 | 1/4''SAE | 580 | 395*145*318 | 16.6 | 10 |
| 7.0 | 198 | 8.0 | 226 | 2*10-1 | 15 | 1 | 1/4''SAE | 500 | 396*145*318 | 17 | 10 |
