| Model |
|---|
| GBC-6S |
| GBC-10 |
| GBC-12 |
| GBC-16 |
| GBC-19 |
| GBC-22 |
| GBC-28 |
| GBC-35 |
| GBC-42 |
| GBC-54 |
| GBC-67 |
| GBC-79 |
| GBC-67A |
| GBC-79A |
| Size (inch/mm) | O.D. (mm) | Kv (m³/h) |
|---|---|---|
| 1/4"(Φ6) | Φ10 | 2 |
| 3/8"(Φ10) | Φ14 | 5.7 |
| 1/2"(Φ12) | Φ14 | 10.6 |
| 5/8"(Φ16) | Φ14 | 14.1 |
| 3/4"(Φ19) | Φ19 | 20.4 |
| 7/8"(Φ22) | Φ19 | 28.2 |
| 1 1/8"(Φ28) | Φ25 | 52 |
| 1 3/8"(Φ35) | Φ31 | 80 |
| 1 5/8"(Φ42) | Φ37 | 121 |
| 2-1/8"(Φ54) | Φ50 | 200 |
| 2-5/8"(Φ67) | Φ50 | 200 |
| 3-1/8"(Φ79) | Φ50 | 200 |
| 2-5/8"(Φ67) | Φ60.5 | 310 |
| 3-1/8"(Φ79) | Φ73 | 700 |
|
tYPE
|
|---|
| GBC-6S |
| GBC-10 |
| GBC-12 |
| GBC-16 |
| GBC-19 |
| GBC-22 |
| GBC-28 |
| GBC-35 |
| GBC-42 |
| GBC-54 |
| GBC-67 |
| GBC-79 |
| GBC-67A |
| GBC-79A |
|
A
|
B
|
C
|
D
|
E
|
F
|
K
|
M
|
j
|
H
|
L
|
|---|---|---|---|---|---|---|---|---|---|---|
| 57 | 6 | 6.5 | 10 | 14 | 0 | 32.5 | M4 | 20 | 16 | 110 |
| 73 | 9 | 10.1 | 16 | 14.5 | 2 | 38 | M4 | 30 | 22 | 138 |
| 83 | 10 | 12.8 | 16 | 14.5 | 2 | 38 | M4 | 30 | 22 | 159 |
| 83 | 12 | 16.1 | 16 | 14.5 | 2 | 36 | M4 | 30 | 22 | 159 |
| 96 | 14 | 19.1 | 22 | 19 | 3 | 43 | M4 | 36 | 30 | 185 |
| 96 | 17 | 22.3 | 22 | 19 | 3 | 43 | M4 | 36 | 30 | 185 |
| 108 | 20 | 28.7 | 28 | 24 | 4 | 52.5 | M4 | 44 | 38 | 208 |
| 130 | 25 | 35.2 | 35 | 30 | 5 | 64 | M6 | 44 | 48 | 251 |
| 145 | 29 | 41.5 | 41.3 | 35 | 6 | 74 | M6 | 56 | 55 | 281 |
| 157 | 35 | 54.2 | 54 | 45.5 | 9 | 83.5 | M6 | 56 | 55 | 305 |
| 157 | 37 | 67 | 54 | 45.5 | 9 | 83.5 | M6 | 63 | 74 | 305 |
| 157 | 40 | 79.6 | 54 | 45.5 | 9 | 83.5 | M6 | 63 | 74 | 305 |
| 171 | 37 | 67 | 66.8 | 54 | 16 | 94 | M6 | 72 | 84 | 343 |
| 207 | 37 | 79.6 | 79.4 | 64 | 16 | 104 | M6 | 80 | 86 | 413 |
