part
Number
|
|---|
| 4002020064 |
| / |
| 4002020065 |
| / |
| / |
| 4002020054 |
| 4002020055 |
| 4002020056 |
| 4002020057 |
| 4002020058 |
| 4002020059 |
| 4002020047 |
| 4002020048 |
| 4002020049 |
| 4002020050 |
| / |
| 4002020051 |
| 4002020052 |
| 4002020053 |
| 4002020066 |
| 4002020060 |
| 4002020062 |
| 4002020061 |
| 4002020063 |
|
model
number
|
refrigerant
type
|
Gauge Diameter
mm
|
Pressure Scale
psi
|
Hose
inch
|
Length
cm
|
Package
type
|
Quick Couplers
set
|
|---|---|---|---|---|---|---|---|
| VMG-2-R32 | R32 | Ø80 | 0~80;-30~500 | 1/4-5/16, 1/4-1/4 | 120 | Blow Case | / |
| VMG-2-R32-B-03 | R32,R407,R410A,R134a | Ø68 | 0~80;-30~500 | / | / | Blister Packing | / |
| VMG-2-1234yf | 1234yf | Ø80 | 0~400;-30~130 | M12x1.5 | 150 | Blow Case | / |
| VMG-2-R600-B | R600/R600a/R290 | Ø68 | -30~435;-30~130 | 1/4-1/4 | 120 | Blow Case | / |
| VMG-2-R600-B-03 | R600/R600a/R290 | Ø68 | -30~435;-30~130 | / | / | Blister Packing | / |
| VMG-2-R22 | R404A/R407C/R134a/R22 | Ø80 | -30~400;-30~140 | 1/4-1/4 | 120 | Blow Case | / |
| VMG-2-R22-02 | R404A/R407C/R134a/R22 | Ø80 | -30~400;-30~140 | 1/4-1/4 | 120 | Blister Packing | / |
| VMG-2-R22-03 | R404A/R407C/R134a/R22 | Ø80 | -30~400;-30~140 | / | / | Blister Packing | / |
| VMG-2-R22-B | R404A/R407C/R134a/R22 | Ø68 | -30~400;-30~140 | 1/4-1/4 | 120 | Blow Case | / |
| VMG-2-R22-B-02 | R404A/R407C/R134a/R22 | Ø68 | -30~400;-30~140 | 1/4-1/4 | 120 | Blister Packing | / |
| VMG-2-R22-B-03 | R404A/R407C/R134a/R22 | Ø68 | -30~400;-30~140 | / | / | Blister Packing | / |
| VMG-2-R410A | R410A | Ø80 | 0~800;-30~500 | 1/4-5/16, 1/4-1/4 | 150 | Blow Case | / |
| VMG-2-R410A-02 | R410A/R407C/R134a/R22 | Ø80 | 0~800;-30~500 | 1/4-5/16, 1/4-1/4 | 150 | Blow Case | / |
| VMG-2-R410A-03 | R410A/R407C/R134a/R22 | Ø80 | 0~800;-30~500 | 1/4-5/16, 1/4-1/4 | 150 | Blister Packing | / |
| VMG-2-R410A-04 | R410A/R407C/R134a/R22 | Ø80 | 0~800;-30~500 | / | 150 | Blister Packing | / |
| VMG-2-R410A-05 | R410A/R407C/R134a/R22 | Ø80 | 0~800;-30~500 | 1/4-5/16, 1/4-1/4 | 150 | Blister Packing | / |
| VMG-2-R410A-B | R410A/R407C/R134a/R22 | Ø68 | 0~800;-30~500 | 1/4-5/16, 1/4-1/4 | 120 | Blow Case | / |
| VMG-2-R410A B02 | R410A/R407C/R134a/R22 | Ø68 | 0~800;-30~500 | 1/4-5/16, 1/4-1/4 | 120 | Blister Packing | / |
| VMG-2-R410A-B03 | R410A/R407C/R134a/R22 | Ø68 | 0~800;-30~500 | / | / | Blister Packing | / |
| VMG-4-R410A | R410A | Ø80 | 0~800;-30~500 | 1/4-5/16, 1/4-1/4,3/8 | 150 | Blow Case | / |
| VMG-2-R134a | R134a | Ø80 | 0~400;-30~140 | 1/4-1/4 | 120 | Blow Case | VHF-SA 1set |
| VMG-2-R134a-B | R134a | Ø68 | 0~400;-30~140 | 1/4-1/4 | 120 | Blow Case | VHF-SA 1set |
| VMG-2-R134a-02 | R134a | Ø80 | 0~400;-30~140 | 2*1/2-M14x1.5, 1/2 | 120 | Blow Case | VHF-SA 1set |
| VMG-2-R134a-B02 | R134a | Ø68 | 0~400;-30~140 | 2*1/2-M14x1.5, 1/2 | 120 | Blow Case | VHF-SA 1set |
