| model |
|---|
| Power Supply |
| Motor |
| Motor Speed |
| Maximal Current Draw |
| Compressor |
Automatic Safety Shut-off |
Recovery Rate(kg/min) (Vapor/Liquid/ Push-pull) |
| Operating Temperature |
| Dimension |
| Weight |
| Vrr24l-r32 | Vrr12l-r32 | VRR12los-r32 | vrr24los-r32 |
|---|---|---|---|
| 220-240V~50/60HZ, 115V~60HZ | 220-240V~50/60HZ, 115V~60HZ | 220-240V~50/60HZ, 115V~60HZ | 220-240V~50/60HZ, 115V~60HZ |
| 3/4HP | 3/4HP | 1HP | 1HP |
| 1450/1750rpm(220V) / 1750rpm(115V) | 1450/1750rpm(220V) / 1750rpm(115V) | 1450/1750rpm(220V) / 1750rpm(115V) | 1450/1750rpm(220V) / 1750rpm(115V) |
| 4A(220V) / 4A(115V) | 4A(220V) / 8A(115V) | 5A(220V) / 10A(115V) | 5A(220V) / 10A(115V) |
| Oil-less,Air-cooled,Piston style | Oil-less,Air-cooled,Piston style | Oil-less,Air-cooled,Piston style | Oil-less,Air-cooled,Piston style |
38.5bar/3850kPa(558Psi) |
38.5bar/3850kPa(558Psi) |
38.5bar/3850kPa(558Psi) | 38.5bar/3850kPa(558Psi) |
| Category III: 0.2/1.6/4.6 Category IV: 0.25/1.8/5.6 Category V: 0.25/2.2/6.3 |
Category III: 0.2/1.6/4.6 Category IV: 0.25/1.8/5.6 Category V: 0.25/2.2/6.3 |
Category III: 0.4/3.0/7.5 Category IV: 0.5/3.5/8.5 Category V: 0.5/3.5/9.5 |
Category III: 0.4/3.0/7.5 Category IV: 0.5/3.5/8.5 Category V: 0.5/3.5/9.5 |
| 0ºC-40ºC | 0ºC-40ºC | 0ºC-40ºC | 0ºC-40ºC |
| 450x250x355mm | 450x250x355mm | 450x250x355mm | 450x250x355mm |
| 13kg | 14.2kg | 13.5kg | 14.7kg |
