Model
spec
|
|---|
| VRP-6DV |
| VRP-8DV |
|
fLOW RATE
50hz (cfm)
|
FLOW RATE
50hz (l/min)
|
Flow rate
60hz (cfm)
|
flow rate
60hz (l/min)
|
UL. VACUUM
(PARTIAL PRESSURE) (pa)
|
UL. VACUUM
(TOTAL PRESSURE) (Micron)
|
Power
(H/P)
|
Inlet Port
(inches)
|
oil capacity
(ml)
|
Dimension
(mm)
|
Weight
(kg)
|
MOQ
(pcs)
|
|---|---|---|---|---|---|---|---|---|---|---|---|
| 6.0 | 170 | 6.0 | 170 | 2*10-1 | 15 | 3/4 | 1/4''&3/8''SAE | 600 | 346*145*302 | 11.5 | 10 |
| 8.0 | 226 | 8.0 | 226 | 2*10-1 | 15 | 3/4 | 1/4''&3/8''SAE | 600 | 346*145*302 | 11.5 | 10 |
