| Order no. | |
|---|---|
|
| model no. | sizes(mm) | cutting thickness(mm) | oxygen pressure(mpa) | acetylene pressure(mpa) |
|---|---|---|---|---|
| 000 | 0.7 | 1-3 | 0.15-0.2 | 0.035 |
| 00 | 0.8 | 3-6 | 0.15-0.2 | 0.035 |
| 0 | 1 | 6-10 | 0.2-0.25 | 0.035 |
| 1 | 1.2 | 10-20 | 0.2-0.25 | 0.035 |
| 2 | 1.5 | 20-40 | 0.25-0.32 | 0.045 |
| 3 | 1.8 | 40-60 | 0.25-0.35 | 0.06 |
| 4 | 2.1 | 60-80 | 0.32-0.4 | 0.07 |
| 5 | 2.5 | 80-125 | 0.32-0.4 | 0.085 |
